14.1 inch Education YOGA

Information

Descriptions

SOC

Intel Tiger Lake-U

n i7-1185G7, Quad-Core; Speed: GHz

n i7-1175G7, Quad-Core; Speed: GHz

n i5-1145G7, Quad-Core; Speed: GHz

n i5-1135G7, Quad-Core; Speed: GHz

n i3-1115G4, Dual-Core; Speed: GHz

Memory

LPDDR4 On Board

Or

DDR4 Sodimm

n LPDDR4 Speed up to 2400MHz

n Support 4GB-32GB

n DDR4 Speed up to 2400MHz

n Support 4GB-32GB

Storage

eMMC

n Support 32GB / 64GB /128GB eMMC

Ø Support eMMC 5.1

SSD
<Optional>

n Support  SSD 128-512GB

n Support SATA or PCIE (M.2 2280)

HDD
<Optional>

n Support  DHH 512-1TB

Ø Support SATA 2.5inch

Audio Codec

Realtek

ALC269Q-VX3-GR

n Azalia integrated audio

n 2.1 channels sound outputs support

n Cortana support on Windows 10

n Digital MIC array

LAN Controller

<Optional>

Realtek

RTL8111HS-CG

n Supports 10/100/1000 Mb/Sec

KBC

ITE

IT8987E/BX

n ACPI 2.0b compliant

MicroSD　  Card reader

Realtek

RTS5170-GR

n SD, SDXC, SDHC

n USB2.0 interface

Hall Sensor

WH251E-3/TR

n Micropower operation

n Operation with magnetic field of either north or south pole

n Chopper stabilized

n Superior temperature stability

LCD

14.1 IPS

n 14.1” IPS 1920 x 1080

n Brightness 250nits，contrastratio800(typ)

n eDP interface

Keyboard

n Integrated QWERTY keyboard w/ Hot key

n 83 UK / 84 US KEY K/B

n Multi-languages Supported

n Physical Chocolate KB

Pointing Device

HIDI2C

n Click Pad with Left / Right Click and scrolling Bar.

n I2C interface

n Support Windows Precision Touchpad (PTP)

Touch Controller

Goodix

GT7385P

n Mutual Capacitive Sensing Techniques

n UP to 10 finger detection and simultaneous tracking

n Windows 10 desktop certified touch solutions

n Up to 100Hz report rate

n Sensor size up to 10 inch diagonal

Touch screen

G+G

n Support 10-points multi-touch, G+G type

n Capacitive multi-touch

n I2C Interface

n Support palm rejection

Active Stylus

ME-MPP413B

n Stylus ME-MPP413B

n support MPP 1.51

Wireless LAN /  Bluetooth

1x1ac Combo

AC9461

n 802.11ac 1x1 (5GHz/2.4GHz dual band support)

n Bluetooth 5.1

n M.2 2230 supported

2x2ac Combo

AC9560

<Optional>

n 802.11ac, 2x2 (5GHz/2.4GHz dual band support)

n Bluetooth 5.1

n M.2 2230 supported

Accelerometer

(G-sensor)<default in Yoga type>

BOSCH

BMA253

n Accelerometer and gyroscope combine

n Display profile switching (portrait/landscape, face-up/face-down switching)

n Flat detection

n I²C, 2x digital interrupt pins

Accelerometer

Gyroscope

<Optional in Yoga type>

BOSCH

BMI160

n Accelerometer and gyroscope combine

n Display profile switching (portrait/landscape, face-up/face-down switching)

n Flat detection

n I²C, 2x digital interrupt pins

ALS

(Ambient Light-Sensor)

<Optional>

Capella

CM32181A3OP

n LCD backlight luminance auto adjustment

n Standard SM Bus protocol interface

e-Compass

<Optional>

BOSCH

BMM150

n Geomagnetic combination

n Compensated compass

n Map rotation

n I2C serial interface

LTE
<Optional>

Fibocom

L830-EB-01

n LTE FDD: Band 1,3,7,8,20,28,

n WCDMA/HSPA+: Band I, V, VIII

n M.2 Key-B, 30 x 42 x 2.3mm

n USB 2.0 interface

n Data Service Up to 300Mbps DL/50Mbps UL

n Supports AGPS

Battery

n Polymer 3 cell 3S1P 5000mAh

n Li-Polymer Battery, SW Gas Gauge IC,soft pack,non-removable, 3s1p/11.4V/5000mAh/57Wh.

Adapter

65W

n DC Output: 19V/3.42A

n DC in plug

n Automatics Voltage adjustment between 100 and 240VAC

n Input Frequency 50/60Hz

n Surge protection

I/O Port

1 x DC-in(5.5Ø)

2 x USB 3.2 Gen1 Type-A

2 x USB 3.2 Gen1 Type-C (USB3.2, Data/PD/DP)

1 x combo audio jack for headphone/microphone

1 x HDMI Type-A 2.0

1 x SD 2.0 card reader

1 x Micro SIM slot <Optional>

1 x RJ45 <Optional>

1 x SIM <Optional>

System Status

Indication

n When power on: White LED always on,大小写White LED，数字White LED。

n Power charging indicator LED (Full: Green / Charging: Red)

n Low battery (<20%): Red, blink every one second.

n LAN Link:10M Off / 100M Green / 1000M Orange / Act: Green

Power Button

n On/ Off: Programmable Power Buttons to Windows

n Press power button down for 1 second to enter suspend mode

n Press power button down for 4 seconds to power off system

Speaker

n Build-in 2 stereo speakers

n Speaker: 2W , 4Ω

Microphone

n Default: 2 digital mic (One in Camera)

n Support Windows 10 Cortana compliance.

Camera

n Front Camera：2M FF W/Blue LED

n With D-MIC*1

n USB 2.0 interface

n Resolution support 2M(4:3 format)still image and HD 720P(1280x720，16：9) motion image

OS

n Windows 10 (64bit)

n WHLK LOGO

System BIOS

AMI

n Support ACPI 5.0

n Support external USB flash memory card boot up.

Function Key

n F1 – Mute

n F2 – Volume down

n F3 – Volume Up

n F4 –Switch display device

n F5 –Brightness down

n F6 –Brightness up

n F7 – Setting

n F8 – Play/Pause Media

n F9 – Cortana

Measurements

n Dimension:343.4*234*22.3mm

n Weight:1.8kg (TBC)

Battery Life

n Battery Life : 8-10 hour with Tablet Mark 2017 (With SSD SKU)(TBC)

***Base on 14.1” LCD and defined brightness, Wi-Fi on, and camera disabled. Actual battery life may vary based on product settings, usage patterns and environmental conditions.

Certification

EMC

n FCC/CE

RF

n CE (Wifi only for Europe，LTE by request)

n FCC(LTE by request)

Safety&

Environment

n CB

n UL (by request)

n WEEE(Declaration)

n RoHS (Declaration)

Design Ready

n Energy Star Compliance 8.0

n Erp 6

n CEC

Validation

dTPM2.0

SLB 9670

<Optional>

n Meeting IntelTXT, Microsoft Windows and Google Chromebook certification criteria for successful platform qualification

n SPI interface

Validation

n Drop test MIL-STD-810G(70cm)

n IP54

Fingerprint

<Optional>

n Touch pad

n SPI interface

n Windows Hello supported

iKES
<Optional>

n Education Software (not support in Win10 S mode)
